The cable supply electricity to the electrical control system of the transfer trolley. Then we operate the trolley, such as start, stop, forward & reverse,etc.

>> Product presentation


steel tube transfer cart
Steel plate electric transfer cart
Steel tube battery powered transfer car



>> Visit and inspection service





>> Features:


1. Cable powered, which supplies electricity to the car
2. Traveling on track/rails
3. Flat decking
4. Steel wheel & box beam structure
5. Heavy loading capacity: 1-300 ton
6. AC motor drive

>> Characters


It has advantages of low noise level, maximum safety for operators and for material handled and is easy to operate. BEFANBY can adjust the operating system to each application by wireless remote control systems and pendant buttons.
These carts are widely applied to suit varied jobs and applications. Our line of trolleys is used on rail or square bar for the purpose of a definite travel. Electric Transfer Vehicles are extensively used in painting shops, quarries, warehouses and cross-bay workshops in order to transfer loads in a hassle-free manner.

Model

KPJ-2t

KPJ-16t

KPJ-40t

KPJ-63t

KPJ-80t

Rated load(t)

2

16

40

63

80

Table size(mm)

Length

2000

4000

5000

5600

6000

Width

1500

2000

2500

2500

2600

Height

500

600

700

800

900

Wheel base(mm)

1200

2800

3800

4300

4700

Rail Inner Gauge (mm)

1200

1435

1435

1435

1800

Wheel Diameter(mm)

Ф270

Ф350

Ф500

Ф600

Ф600

Wheel Quantity

4

4

4

4

4

Ground Clearance (mm)

50

50

50

75

75

Running speed(min)

25

20

20

20

20

Motor Power(Kw)

0.8

2.2

5.5

7.5

7.5

Running distance(m)

25

25

50

50

50

Max Wheel Load(KN)

14.4

64.5

142.8

221.4

278.4

Reference Weight(t)

2.5

5.2

7.3

10.5

12.3

Recommended Rail Model

P15

P24

P43

P50

P50

Note:
1. Load capacity,table size and rail gauge can be customized.
2. Options:
a.Cable reel (Spring type , magnetic coupling type, motor-driven type)
b.Automatic stop when detecting obstacle or person, limit switches(to limit travel)
c.Operation way(hand held control pendant,remote radio control or operation platform with the cart)
d.Electrical parts(imported or made in China);
e.Power supply position(middle or two ends)
f.Variable speed device(VCD)
g.Can be designed to meet special working environment such as high temperature.
