The transfer cart is feed AC 380V/415V/440V by cable. Through the electrical control system, the cart starts, stops, forward and backward, etc.

>> Product presentation


Power Steel Cable Reel cart
Heavy load Transfer bogies
heavy load motorized transfer bogie



>> Visit and inspection service





>> Features:


1. Electric powered
2. Rail guided
3. With hydraulic lifting system
4. Capacity range: up to 300MT
5. Unlimited working time
6. Wireless remote control

>> Characters


All transfer carts are equipped with state-of-the-art safety equipment, such as warning light, horns, bumpers, dead man controls and E-stop buttons.
Heavy load Transfer bogies are mainly used to solve maneuverability problems in tight spaces. You can achieve tight turn radius. The propulsion can be either electric (for in-plant load transports) or diesel (for long distances).

This type of transfer vehicles can be equipped with hydraulic lifting system for palletized cargoes in order to optimize space as much as possible.

Model

KPJ-100t

KPJ-150t

Rated load(t)

100

150

Table size(mm)

Length

6500

10000

Width

2800

3000

Height

1000

1200

Wheel base(mm)

4900

7000

Rail Inner Gauge (mm)

2000

2000

Wheel Diameter(mm)

Ф600

Ф600

Wheel Quantity

4

8

Ground Clearance (mm)

75

75

Running speed(min)

20

18

Motor Power(Kw)

11

15

Running distance(m)

50

50

Max Wheel Load(KN)

343.8

265.2

Reference Weight(t)

14.1

26.2

Recommended Rail Model

QU100

QU100

Note:
1. Load capacity,table size and rail gauge can be customized.
2. Options:
a.Cable reel (Spring type , magnetic coupling type, motor-driven type)
b.Automatic stop when detecting obstacle or person, limit switches(to limit travel)
c.Operation way(hand held control pendant,remote radio control or operation platform with the cart)
d.Electrical parts(imported or made in China);
e.Power supply position(middle or two ends)
f.Variable speed device(VCD)
g.Can be designed to meet special working environment such as high temperature.
