Steel scrap handling carriage gets the electricity from cable drum. It adopts magnetic coupling cable reel to realize 200m running distance. 3 phase AC power provides the electricity for metallurgical motor which drive speed reducer and wheel to realize the carriage movement, such as start, stop, forward, backward etc.

>> Product presentation


Battery Transfer Carriages
Steel scrap handling carriage
steel scrap handling equipment


>> Features:

◆ Anti-high temperature
◆ Scale system
◆ Special design scrap basket holder
◆ Run on rails
◆ High using frequency,18-24 hours working
◆ Sensor device

>> Characters


◆ Steel welding box beam cart body
◆ SKF,FAG bearing
◆ SIMENS motor
◆ Sensor device
◆ Automatic wind and unwind the cable
Steel scrap handling carriage is used in large scale metallurgy or refining line,especially for steel plant. In order to increase efficiency, we can design weighting system to realize automatic weighting for steel scrap.

Model

KPT-2t

KPT-40t

KPT-80t

KPT-100t

KPT-150t

Rated load(t)

2

40

80

100

150

Wheel base(mm)

1200

3800

4700

4900

7000

Rail Inner Gauge (mm)

1200

1435

1800

2000

2000

Wheel Diameter(mm)

Ф270

Ф500

Ф600

Ф600

Ф600

Ground Clearance (mm)

50

50

75

75

75

Motor Power(Kw)

0.8

5.5

7.5

11

15

Max Wheel Load(KN)

14.4

142.8

278.4

343.8

265.2

Reference Weight(t)

2.3

7.2

12.1

13.9

26

Recommended Rail Model

P15

P43

P50

QU100

QU100

◆ Load capacity, table size, rail gauge, speed can custom per client’s demand.
◆ Control way: push button pendant, remote control, operator platform mounted on cars
◆ Provide the optimized solution according to actual application condition.
