The cable supply electricity to the electrical control system of the transfer trolley. Then we operate the trolley, such as start, stop, forward & reverse,etc.

>> Product presentation


Interbay Motorized Transfer Trolley
Transfer Trolley Cars
rail trolley for inter-bay transportation


>> Features:

◆ Cable powered, which supplies electricity to the car
◆ Traveling on track/rails
◆ Flat decking
◆ Steel wheel & box beam structure
◆ Heavy loading capacity: 1-300 ton
◆ AC motor drive




>> Characters


It has advantages of low noise level, maximum safety for operators and for material handled and is easy to operate. BEFANBY can adjust the operating system to each application by wireless remote control systems and pendant buttons.
These carts are widely applied to suit varied jobs and applications. Our line of trolleys is used on rail or square bar for the purpose of a definite travel. Electric Transfer Vehicles are extensively used in painting shops, quarries, warehouses and cross-bay workshops in order to transfer loads in a hassle-free manner.

Model

KPJ-2t

KPJ-16t

KPJ-40t

KPJ-80t

KPJ-150t

Rated load(t)

2

16

40

80

150

Rail Inner Gauge (mm)

1200

1435

1435

1800

2000

Wheel Diameter(mm)

Ф270

Ф350

Ф500

Ф600

Ф600

Ground Clearance (mm)

50

50

50

75

75

Motor Power(Kw)

0.8

2.2

5.5

7.5

15

Running distance(m)

25

25

50

50

50

Max Wheel Load(KN)

14.4

64.5

142.8

278.4

265.2

Reference Weight(t)

2.5

5.2

7.3

12.3

26.2

Recommended Rail Model

P15

P24

P43

P50

QU100

The transfer trolley can be manufactured according to your requirements and needs, such as the loading capacity, trolley dimensions, even the brands of the electrical parts.
