The transfer cart is feed AC 380V/415V/440V by cable. Through the electrical control system, the cart starts, stops, forward and backward, etc.

>> Product presentation


Molten Metal Handling
Ladle transfer car

metal ladle transfer cart
Hot metal ladle conveyer transfer cart


>> Features:

◆ Handling ladle
◆ Large capacity: 1-300MT
◆ High temperature proof
◆ Max. Running distance: 200 meters
◆ Cable powered
◆ With braking system




>> Characters


◆ The transfer carts are AC motor driven and suitable for non-stop working and high temperature working environment.
◆ The carts can be easily operated, either by radio remote control or push button pendant.
The transfer cart is suitable for heavy duty steel production industry, such as steel ladle/ billets/ hot rolled coil/ bloom/ pipe etc. Besides, it also can be used outside, for example, transferring material on dock.

Model

KPT-2t

KPT-16t

KPT-63t

KPT-100t

KPT-150t

Rated load(t)

2

16

63

100

150

Wheel base(mm)

1200

2800

4300

4900

7000

Rail Inner Gauge (mm)

1200

1435

1435

2000

2000

Wheel Diameter(mm)

Ф270

Ф350

Ф600

Ф600

Ф600

Ground Clearance (mm)

50

50

75

75

75

Motor Power(Kw)

0.8

2.2

7.5

11

15

Max Wheel Load(KN)

14.4

64.5

221.4

343.8

265.2

Reference Weight(t)

2.3

5

10.3

13.9

26

Recommended Rail Model

P15

P24

P50

QU100

QU100

◆ With load capacities that range from 5 Ton to 300 Ton, our industrial transfer bogies are equipped with single and double flange steel wheels.
◆ Power supply to the transfer car: through cable reel, festoon cable system or covered shrouded bus bar as per the need.
