This cargo handling cart is powered by the conductor rail. 380v AC power is step down 36v safe voltage through transformer and separately connect with rails. Then electricity is passed to the cart by wheels . Hydraulic lifting device is installed to facilitate load and unload.

>> Product presentation


Cargo handling cart
Cargo handling car
rail powered cart


>> Features:

◆ Power supply of low voltage rails
◆ Cast steel 55 wheel
◆ Steel box beam structure
◆ 36v safe voltage
◆ Variable speed from 0 to 20m/min

>> Characters


◆ Products are ISO9001 certified
◆ Safety device such as bumpers, warning light, position switches
◆ Be suitable for middle and long distance transportation
◆ Equipped with PLC program and speed controller
Cargo handling cart applied in steel mill mainly is used for transportation steel tube and pipes, steel coil, steel billet, ladle, steel slag etc

Model

KPDZ-2t

KPDZ-25t

KPDZ-40t

KPDZ-50t

KPDZ-63t

Rated load(t)

2

25

40

50

63

Table size(mm)

Length

2000

4500

5000

5500

5600

Width

1500

2200

2500

2500

2500

Height

450

600

650

650

750

Wheel Quantity

4

4

4

4

4

Running speed(min)

0-25

0-20

0-20

0-20

0-20

Transformer Quantity

1

1

1

1

1

Running distance(m)

80

80

60

50

50

Reference Weight(t)

2.8

6.5

7.6

8

10.8

◆ Load capacity, table size, rail gauge, speed can custom per client’s demand.
◆ Control way: push button pendant, remote control, operator platform mounted on cars
◆ Provide the optimized solution according to actual application condition.
