◆ The rail guided cart is powered by low-voltage conductor rails, which is embedded in the ground. Such as, 380V/ 440V AC power supply stepdown and rectified into 36VDC. This DC power will given connected to rails.
◆ Transfer cart wheel which have contact over rail, pickup supply from rail through wheels and energize the DC geared motor which drive the transfer cart wheels.

>> Product presentation


Detachable transfer trolley
material handling cart
heavy duty steel carts


>> Client



>> Features:


◆ Oversize
◆ Low-voltage rail powered
◆ Die handling
◆ Motor driven
◆ Customized cart decking
◆ Applied in mold factory

>> Characters


The trolley is divided into two or three parts for the convenience of transportation and loading. It suits to transfer die, besides, the transfer cars are designed to accommodate the needs of a wide range of industries. They are designed to operate on rails and are used to transport heavy materials across bays or in areas not serviced by an overhead crane.
The material handling cart are used to transfer heavy load material in heavy manufacturing industry including Steel, Aluminum, Automotive, Stamping, Heavy Manufacturing and several others. Handling material such as steel coil, billets, bloom, ladle & scrap, locomotive, vehicle, work pieces to painting shops or blasting room, etc.

Model

KPDZ-10t

KPDZ-25t

KPDZ-40t

KPDZ-63t

Rated load(t)

10

25

40

63

Table size(mm)

Length

5000

5500

7000

8000

Width

4000

4000

4200

4400

Height

650

700

700

1400

Wheel base(mm)

3800

4200

5000

6500

Rail Inner Gauge (mm)

2500

2500

3800

4000

Wheel Diameter(mm)

Ф350

Ф400

Ф500

Ф650

Wheel Quantity

4

4

4

8

Ground Clearance (mm)

50

50

50

75

Running speed(min)

0-25

0-20

0-20

0-20

Motor Power(Kw)

3

3.5

5.5

7.5

Transformer Power(KVA)

5

6.8

10

20

Transformer Quantity

1

1

1

1

Running distance(m)

80

80

80

50

Recommended Rail Model

P24

P38

P43

P50

◆ The configuration of the electric powered transfer cart can be designed according to your requirement.
◆ Power Supply: storage battery, cable, festoon cable, shrouded busbar, low-voltage rails are available.
◆ Safety devices: automatical stop when detecting obstacles; bumper; limit switch, etc.
