Cold roll rail transport truck for hot dip galvanized plant
- Tel.: +8615736919601
- Mobile:+86 15736919601
- Fax: +86-373-3020456
- E-mail:info@perfte.com
>> Product presentation
>> Features:
◆ V-deck◆ Load from 1ton to 300tons
◆ Steel welding box beam cart frame
◆ AC motor drive
>> Characters
◆ Track mounted
◆ High temperature proof
◆ VFD adjust speed
◆ Shift distance up to 200m
◆ proximity switch
|
Model |
KPT-2t |
KPT-25t |
KPT-63t |
KPT-100t |
KPT-150t |
||
|
Rated load(t) |
2 |
25 |
63 |
100 |
150 |
||
|
Wheel base(mm) |
1200 |
3200 |
4300 |
4900 |
7000 |
||
|
Rail Inner Gauge (mm) |
1200 |
1435 |
1435 |
2000 |
2000 |
||
|
Wheel Diameter(mm) |
Ф270 |
Ф400 |
Ф600 |
Ф600 |
Ф600 |
||
|
Ground Clearance (mm) |
50 |
50 |
75 |
75 |
75 |
||
|
Motor Power(Kw) |
0.8 |
3 |
7.5 |
11 |
15 |
||
|
Max Wheel Load(KN) |
14.4 |
94.5 |
221.4 |
343.8 |
265.2 |
||
|
Reference Weight(t) |
2.3 |
6 |
10.3 |
13.9 |
26 |
||
|
Recommended Rail Model |
P15 |
P38 |
P50 |
QU100 |
QU100 |
||
◆ Control way: push button pendant, remote control, operator platform mounted on cars
◆ Provide the optimized solution according to actual application condition.
