The Turning Transfer Vehicle is our patent product.It can move on S shape,Arc shape and combined rail and arc rail.Small turning radius,stable and flexible turn.Our most advantage is that we optimize the complicated steering mechanism and control mechanism.It is our characterized product.It reduces the production cost and maintenance simply.
Feature:
1. Turning Transfer Vehicle can curve on the track
2. It is more convenient to transport goods and achieve various needs.
3. Turning Transfer Vehicle Bearing problem: Our transfer vehicle can achieve a load-bearing level of 1-200 tons.
Applications:
Heavy industry, light industry, machinery, petroleum, metallurgy, mining, chemical, ship, etc., can handle steel coils, aluminum coils, galvanized coils, transformers, cable reels, castings, motors, containers, compartments, containers, pressure vessels, etc.
Model | BDG-2t | BDG-20t | BDG-50t | BDG-100t | BDG-150t | |
Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
Table Size(mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 | |
Heigth(H) | 450 | 550 | 650 | 850 | 1200 | |
Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 | |
Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 | |
Wheel Quantity | 4 | 4 | 4 | 4 | 8 | |
Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | |
Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 | |
Motor Power(kw) | 0.8 | 2.5 | 5.5 | 11 | 15 | |
Transformer Power(KVA) | 3 | 6.8 | 10 | 30 | 30 | |
Transformer Quanity | 1 | 1 | 1 | 1 | 1 | |
Running Distance(m) | 70 | 70 | 50 | 50 | 50 | |
Max Wheel Load(KN) | 14.4 | 77.7 | 174 | 343.8 | 265.2 | |
Reference Weight(t) | 2.8 | 5.9 | 8 | 14.6 | 26.8 | |
Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 |
Because our products are customized, the specific price depends on the customer's desired product.Because our products are customized, the specific price depends on the customer's desired product.
The Turning Transfer Vehicle needs to go to the site to actually measure the track radius.
The Turning Transfer Vehicle needs to go to the site to actually measure the track radius.
