Heavy load coil transfer car on rail for aluminium and steel factory transportation

Heavy load coil transfer car on rail for aluminium and steel factory transportation

  • Tel.: +86-373-3020456
  • Mobile:+86-13849364134
  • Fax: +86-373-3020456
  • E-mail:Alex@perfte.com
Leave Messages

>> Product presentation


auminium coil transfer car
battery powered coil transfer car
steel coil transfer car
coil transfer trolley


>> Features:

◆ No limit of rail
◆ Steel plate beam structure
◆ Demand ground flatness
◆ Convenient and easy to operate
It is used in steel coil , auminium coils and Cable loop transport

Model

KPX-2t

KPX-10t

KPX-25t

KPX-63t

KPX-100t

KPX-150t

Rated load(t)

2

10

25

63

100

150



Table size(mm)

Length

2000

3600

4500

5600

6500

10000

Width

1500

2000

2200

2500

2800

3000

Height

450

500

600

700

900

1200

Wheel base(mm)

1200

2600

3200

4300

4900

7000

Rail Inner Gauge (mm)

1200

1435

1435

1435

2000

2000

Wheel Diameter(mm)

Ф270

Ф300

Ф400

Ф600

Ф600

Ф600

Wheel Quantity

4

4

4

4

4

8

Ground Clearance (mm)

50

50

50

75

75

75

Running speed(min)

0-25

0-25

0-20

0-20

0-20

0-18

Motor Power

1

1.6

3

6.3

10

15

Battery capacity(Ah)

180

160

250

400

440

600

Battery Voltage(V)

24

48

48

48

72

72

Running Time when full load

4.32

4.8

4

3

3.2

2.9

Running Distance for one Charge(km)

6.5

7.2

4.8

3.6

3.8

3.2

Max Wheel Load(KN)

14.4

42.6

94.5

221.4

343.8

265.2

Reference Weight(t)

2.8

4.2

6.5

10.8

14.6

26.8

Recommended Rail Model

P15

P18

P38

P50

QU100

QU100
